• Sale Off
    uperfect-arduino-touch-screen-7b06

    UPi B706

    $139.99$139.99

Portable Arduino Touch Screen

Sale Off
uperfect-arduino-touch-screen-7b06
First Arduino screen, give users more freedom space to realize various creative projects.

$139.99$139.99

7 インチのタッチ スクリーンは Arduino 用に設計されています。 Arduino IDE のプログラミング ソフトウェアは、ユーザーがさまざまな創造的なプロジェクトをプログラムするのに役立ちます。 Arduino 回路基板が体重、心拍数、明るさ、音、温度、湿度などの他のさまざまなセンサーに接続されている場合、CNC 書き込みマシンを制御して、ペンと紙で入力グラフィックを描画し、音楽の夜を過ごすことができます。音楽の変化に合わせて光がジャンプし、それに応じて光の色が変わります。小型二足歩行ロボットは超音波測距センサーを通じて障害物を回避でき、携帯電話はBluetoothを使用して障害物を回避できます。車の方向などを制御できます。

  • 10-Point
    Touchscreen
  • VESA
    Mount
  • HDMI &
    Type-C

Specifications

Series: UPi

Model: B706

Refresh Rate: 60Hz

Screen Size: 7 inch

Resolution: 1024*600 WSVGA

Display Ratio: 16:9

Viewing Angle: 178°

Panel Type: IPS

Contrast Ratio: 700:1

Brightness: 250 cd/m²

Color Gamut: 72% sRGB

Color Depth: 252K(6bit)

Rated Power: 8W

Material: ABS

Touch Screen: Yes, 10-point touchscreen

Auto Rotation: No

Built-in Battery: No

HDR: Yes

FreeSync: Yes

VESA: Yes, 75*75@M3*6mm

Built-in Speaker: Yes, 2*8Ω 1W

Product Size : 177.8 × 110 × 12 mm (7 × 4.33 × 0.47 inch)

Net Weight:  0.38 kg (0.83 lbs)


What's in the box?

  • 1 × UPERFECT 7 Inch Arduino Touch Screen

  • 1 × HDMI to HDMI Cable
  • 1 × Power Adapter
  • 2 × Touch Cable
  • 2 × Side Panel
  • 4 × Screw
  • 1 × Phillips Screwdriver
  • 1 × Type C to Type C Cable
  • 1 × USB-A to USB-C Cable
  • 1 × Manual
  • 1 × Type-C Board
  • 2 × HDMI Board
  • 1 × Micro USB Board

Interface

  • 1 × USB Type-C for Audio & Video Input

  • 1 × HDMI for Audio & Video Input
  • 1 × DC Port for Power Input
  • 1 × 3.5mm AUX for Audio Output

7 Inch Arduino Screen

[Designed for Arduino] As open-source hardware, Arduino provides a platform for many users to create at an affordable price and low learning cost, and the 7-inch diagonal display is specially designed for Arduino, and its compact body weighs only 0.38 kg ( 0.83 lbs), users can carry it with them, write programs at any time, realize the creation of various projects, and flex their muscles in various creative projects.

[10-Point Touchscreen] 7-inch Arduino touchscreen with IPS is a smooth feel and supports swipe, scroll, drag and pinch gestures to help you get tasks done more efficiently. No extra driver is needed. Connect the touch cable we provide to your device to achieve the touch function.

[Built-in Stand & Fan]The built-in stand on the back can support the monitor on any smooth surface, no need to buy additional stands. The built-in cooling fan increases heat dissipation, reduces the consumption of parts, and prolongs the service life.

[Intelligent Eye Care] Arduino display screen adopts blue light filter technology, a free smart adaptive picture setting that keeps eyes fresh and strain-free; For late-night projects, brightness, and color temperature adjust in any environment, and protect against excessive blue light.

More Powerful
Beyond Your Imagination
0.38 kg (0.83 lbs) Weightless
HDMI &
Type-C
7-inch
Screen Size
72% sRGB
Color Gamut
VESA
Mount
Easy Calibration OSD Touch Menu
  • Free Delivery Worldwide

    Shipping 2-7 days from oversea warehouse or 15-25 days by international express.
  • 2-Year Warranty Policy

    Gain peace of mind with support in 24 hours and 2-Year Warranty
  • 30-Day Risk Free Trial
    Take it home and enjoy them with no hesitate. Contact us within 30 calendar days for returns without hassle.
  • Buy Now, Pay Later
    Shoppay is availble for 4 interest-free payments.
